Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE
Model Number: LCA328T
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $60.00/Sets >=1 Sets
Packaging Details: 1pcs/box with sponge ,100pcs/ctn
Delivery Time: 7 days for samples
Payment Terms: T/T, PayPal
Supply Ability: 3000 Set/Sets per Month
Measure Range: |
0~360 |
Measure Axis: |
X Y |
Zero Output: |
12mA |
Resolution: |
0.02° |
Measure Accuracy: |
0.1° |
Weight: |
90g |
Measure Range: |
0~360 |
Measure Axis: |
X Y |
Zero Output: |
12mA |
Resolution: |
0.02° |
Measure Accuracy: |
0.1° |
Weight: |
90g |
LCA328T Roll Pitch Dual Axis Tilt Sensor Real Time Output Digital Tilt Meter
General Description
The LCA328T series inclinometer which developed by Rion Company is a small volume MEMS dual-axis tilt sensor, because of built-in the latest MEMS production technology inclination unit, small size, long distance transmission can up to over 2000 Meters, strong ability of resisting external electromagnet interference, can be adapted to long-term working in the industry harsh environment.
This product adopts the non-contact measuring principle, can real-time output the current attitude angle, simple to use, no need to find the relative variation of the two surface for mounting. It is a ideal choice for Industrial automation control and platform measuring attitude!
Features
Application
Technical Specification
| LCA318T&328T | CONDITION | PARAMETER | UNIT | |||
| Measure range | ±30 | ±60 | ±90 | 0~360 | ° | |
| Measure axis | X Y | X Y | X Y | X Y | Axis | |
| Zero output | 0° output | 12 | 12 | 12 | 12 | mA |
| Resolution | 0.02 | 0.03 | 0.05 | 0.08 | ° | |
| Measure accuracy | @25℃ | 0.1 | 0.1 | 0.15 | 0.2 | ° |
| Long term. stability | <0.5 | <0.5 | <0.5 | <0.5 | ||
| Zero Temp.coefficient | -40～85℃ | ±0.02 | ±0.02 | ±0.02 | ±0.02 | °/℃ |
| Sensitivity temp-coeffi | -40～85℃ | ≤150 | ≤150 | ≤150 | ≤150 | ppm/℃ |
| Power-on start time | 0.5 | 0.5 | 0.5 | 0.5 | S | |
| Response time | 0.02 | 0.02 | 0.02 | 0.02 | s | |
| Response frequency | 1～20 | 1～20 | 1～20 | 1～20 | Hz | |
| EMC | According to EN61000 and GBT17626 | |||||
| MTBF | ≥45000 hours/times | |||||
| Insulation Resistance | ≥100 MΩ | |||||
| Impact resistance | 100g@11ms, 3 Axial Direction (Half Sinusoid) | |||||
| Anti-vibration | 10grms,10～1000Hz | |||||
| Protection grade | IP67 | |||||
| Cables | standard configuration: 1 meter wearproof,grease proofing,wide temperature,Shielded cables 4*0.3mm2 | |||||
| Weight | 90g (exclude cable) | |||||
▶ INSTALLATION PRECAUTIONS
Please install the tilt sensor according to the correct method. Improper installation will cause measurement error. Pay attention to the first "surface" and the second "line": 1) The mounting surface of the sensor and the measured surface must be tight, flat and stable. The unevenness of the mounting surface is easy to cause the angle error of the sensor measurement.
2) The axis of the sensor and the axis to be measured must be parallel, and the angle between the two axes should be avoided as much as possible
Order Process :
Before order pls contact us for confirm detailed informaiton such as model ,price ,lead time ...etc .
Payment ways :
T/T, WU or Paypal;
Delivery methods & Time :
DHL takes 3-5days , Fedex takes 2-7 days , UPS takes 3-7day , EMS takes 10-25days ;
Quality Policy :
We gurantee 1 year in free charge .
Storage :
Note usually we don't make any items in stock , samples customize time need around 3-7days .
