Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE
Model Number: LCA332A
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $75.00/Pieces
Packaging Details: 1pcs/box ,100pcs/ctn
Delivery Time: 5-10 work days
Payment Terms: T/T, L/C
Supply Ability: 100,PCS,A WEEK
Usage: |
Position Sensor |
Theory: |
Other |
Output: |
Switching Transducer |
Zero Set Function: |
Yes |
Axis: |
Dual Axis With 4 Direction Tilt Measurement |
Resolution: |
0.01degree |
Output: |
Positive/negative Direction |
Working Temp.: |
-40 To +85℃ |
Interface: |
Direct Lead Cable Interface |
Alarm: |
LED Alarming Light |
Size: |
60x60x30mm |
OEM: |
YES |
Usage: |
Position Sensor |
Theory: |
Other |
Output: |
Switching Transducer |
Zero Set Function: |
Yes |
Axis: |
Dual Axis With 4 Direction Tilt Measurement |
Resolution: |
0.01degree |
Output: |
Positive/negative Direction |
Working Temp.: |
-40 To +85℃ |
Interface: |
Direct Lead Cable Interface |
Alarm: |
LED Alarming Light |
Size: |
60x60x30mm |
OEM: |
YES |
SPECIFICATIONS:
| LCA series | Parameter | Unit |
| Measuring range | ±85 | ° |
| Measuring axis | X,Y | |
| Resolution | 0.05 | ° |
| Absolute accuracy | 0.1 | ° |
| Long-term stability | 0.05 | |
| Zero temp. coeffiecient | -40~85°C ±0.01 | °/°C |
| Temp. Sensitivity coefficient | -40~85°C ≤100 | ppm/°C |
| Power on time | 0.1 | S |
| Response time | 0.2 | s |
| Electromagnetic compatibility | Per EN61000 and GBT17626 | |
| MTBF | ≥98000hours/time | |
|
Insulation Resistance |
≥100MΩ |
|
| Impact resistance | 100g@11ms,3 times/axis(half sinusoid) | |
| Anti-shock | 10grms,10~1000Hz | |
| waterproof | IP67 | |
| cable |
1m, durable, grease proof, wide temperature, shield cable, 4 x 0.4 mm2 |
|
| weight | 150g(exlude cable) | |
